This 21.5-inch Full HD TFT LCD module is designed for applications requiring large-scale displays, high-definition imagery, and reliable signal transmission. Utilizing an LVDS (Low Voltage Differential Signaling) interface, it is ideal for industrial control, medical equipment, digital signage, and embedded computing systems, balancing high performance with dependability.

Key Features
This 21.5-inch Full HD TFT LCD module Visual Performance
21.5-inch IPS/ADS panel with 1920×1080 resolution (16:9 aspect ratio) supporting Full HD 1080p.
Typical brightness of 250cd/m² and contrast ratio of 1000:1 for sharp images and true-to-life colors.
Ultra-wide 178° viewing angles (horizontal/vertical) ensuring consistent color across multiple perspectives.
This 21.5-inch Full HD TFT LCD module LVDS Interface Advantages
High-speed, anti-interference LVDS differential signaling (up to 1.1Gbps data rate).
Low-power design (1.2Vlogic levels) suitable for embedded low-power systems.
Simplified wiring: Single/dual-channel LVDS configurations reducing cable clutter and EMI.
This 21.5-inch Full HD TFT LCD module Mechanical Design
Ultra-narrow bezel (<10mm) for seamless integration into modern embedded devices.
VESA 100mm mounting holes and M4 screw holes for flexible installation options.
Module thickness of 8mm (with backlight) for compact device designs.
Expandable Functions
Supports RGB 8/10-bit color depth with sRGB/Adobe RGB color gamut options (wide-gamut version available).
Optional resistive/capacitive/infrared touch panels.
Dual PWM/DC dimming modes for versatile backlight control.
Electrical & Environmental Specifications

Operating Temperature: Standard version 0°C to 50°C / Wide-temperature version (-30°C to 80°C).
Interface: 20/30-pin LVDS connector (0.5mm pitch) supporting JEIDA/VESA standards.
Typical Applications

Industrial: SCADA systems, CNC machine panels, automation monitoring terminals.
Medical: Ultrasonic imaging devices, patient monitors, portable diagnostic terminals.
Commercial: Digital signage, self-service kiosks, conference display systems.
Automotive: In-vehicle infotainment screens, rear-seat entertainment systems, smart cockpits.
Quality & Compliance

Certifications: CE, FCC, RoHS, REACH; optional medical-grade ISO13485 or automotive AEC-Q100 compliance.
Reliability testing: Validated for vibration, shock, and temperature cycling in industrial environments.
3-year warranty with optional upgrades:
Anti-glare (AG)/anti-reflective (AR) coatings.
Optical Clear Adhesive (OCA) bonding for enhanced outdoor visibility.
Custom color calibration and gamma curve adjustments.
Technical Support & Customization

Reference designs for LVDS signal generation boards (compatible with FPGA/SoC platforms).
Engineering services: Custom backlight drivers, touch algorithm optimization, EMI shielding solutions.
System-level integration: GMSL/FPD-Link bridging (long-distance transmission), multi-display tiling control.
Competitive Advantages

Balanced Performance: 21.5-inch Full HD display optimizes size and pixel density for mid-range viewing distances.
Interface Reliability: LVDS ensures signal integrity in electromagnetically complex environments.
Flexible Customization: Deep customization from hardware interfaces to software features for diverse needs.
This module leverages LVDS for efficient data transmission, combining industrial-grade panel design and wide-temperature adaptability to deliver a cost-effective solution for devices requiring stable display performance.
